Nominal Size |
D |
D1 |
d1 |
d2 |
d3 |
L |
L1 |
|||
|
|
PVDF |
PPH |
NPP |
|
|
|
|
|
|
|
|
1/2" |
20mm |
54 |
57.8 |
57.8 |
44 |
30.4 |
18.8 |
15 |
101.57 |
79.9 |
|
3/4" |
25mm |
63 |
66.7 |
66.7 |
50.9 |
35.6 |
23.9 |
20 |
107.68 |
88.3 |
|
1" |
32mm |
72 |
75.8 |
75.8 |
57.8 |
42.5 |
31.2 |
25 |
123.6 |
97.2 |
|
1+1/4" |
40mm |
84.5 |
88.7 |
88.7 |
70.1 |
53 |
38.8 |
32 |
132.35 |
104.7 |
|
1+1/2" |
50mm |
97.9 |
102.3 |
102.3 |
81.5 |
62.3 |
48.8 |
40 |
140.4 |
110.7 |
|
2" |
63mm |
118 |
124.1 |
124.1 |
100.5 |
76.2 |
61.7 |
50 |
162.3 |
128.3 |
